Wecon VD2 SA Series Servo Drives Manual (Lite V1.1)
WECON technology Co., Ltd
13
Figure 3-3 Installation dimensions of VD2F servo drive
3.1.2 Installation site
1
Please install it in an installation cabinet free from sunlight and rain;
2
In a place without vibration;
3
Please do not install in the environment of high temperature, humidity, dust and metal dust;
4
Do not use this product near corrosive and flammable gases such as hydrogen sulfide, chlorine,
ammonia, sulfur, chlorinated gas, acid, alkali, salt, etc., or combustible materials.
3.1.3 Installation environment
The installation environment of the servo drive has a direct impact on the normal function of it and
its service life. Therefore, the installation environment of servo drive must meet the following
conditions:
Item
Specification
Ambient temperature
-10℃ to 40℃ (no freezing)
Ambient humidity
-20% to 90%RH (non-condensing)
Storage temperature
-20℃ to 60℃
Storage humidity
-20% to 90%RH (non-condensing)
Protection grade
IP65
Vibration
Less than 0.5G (4.9m/s2), 10 to 60Hz (non-continuous operation)
Power Systems
TN system*
✎Note:
*: The neutral point of the power system is directly connected to the ground, and the exposed
metal components are connected to the ground through a protective grounding conductor.
