Group P13 Communication input and output terminal
P13-01
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Virtual VDI_1 input value
Operation
setting
Effective
immediately
0
0 to 1
DI/DO
-
When P06-04 is set to 1, DI_1 channel logic is controlled by this function code.
Set value
VDI_1 input level
0
High level
1
Low level
P13-02
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Virtual VDI_2 input value
Operation
setting
Effective
immediately
0
0 to 1
DI/DO
-
When P06-07 is set to 1, DI_2 channel logic is controlled by this function code.
P13-03
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Virtual VDI_3 input value
Operation
setting
Effective
immediately
0
0 to 1
DI/DO
-
When P06-10 is set to 1, DI_3 channel logic is controlled by this function code.
P13-04
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Virtual VDI_2 input value
Operation
setting
Effective
immediately
0
0 to 1
DI/DO
-
When P06-13 is set to 1, DI_4 channel logic is controlled by this function code.
P13-05
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Virtual VDI_5 input value
Operation
setting
Effective
immediately
0
0 to 1
DI/DO
-
When P06-16 is set to 1, DI_5 channel logic is controlled by this function code.
P13-06
☆
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Virtual VDI_6 input value
Operation
setting
Effective
immediately
0
0 to 1
DI/DO
-
When P06-19 is set to 1, DI_6 channel logic is controlled by this function code.
P13-07
☆
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Virtual VDI_7 input value
Operation
setting
Effective
immediately
0
0 to 1
DI/DO
-
When P06-22 is set to 1, DI_7 channel logic is controlled by this function code.
P13-08
☆
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Virtual VDI_8 input value
Operation
setting
Effective
immediately
0
0 to 1
DI/DO
-
When P06-25 is set to 1, DI_8 channel logic is controlled by this function code.
P13-11
Parameter name
Setting method
Effective time
Default
Range
Category
Unit
Virtual VDO_1 input value
Operation
setting
Effective
immediately
0
0 to 1
DI/DO
-
Used to set the input level logic when the DO function selected by VDO_1 is valid
Set value
VDo_1 input level
0
High level
1
Low level
“☆” indicates that the VD2F servo drive does not support this function code.
