Wecon VD2 SA Series Servo Drives Manual (Lite V1.1)
WECON technology Co., Ltd
30
4.2.2 Brake device cable
Connector exterior
terminal pin distribution
Motor flange
WD series
2 1
Pin number
Signal name
1
BR+
2
BR-
40
60
80
WE series

 
Pin number
Signal name
1
DC 24V
2
GND
3
-
80
110
130
Table 4-5 Brake device cable
4.3 Encoder cable connection of servo drive and servo motor
Figure 4-8 Encoder connection line wiring
Connector exterior
Terminal pin distribution
Pin description
Pin
number
Signal
name
Pin
number
Signal
name
1
5V
4
-
2
GND
5
SD+
3
-
6
SD-
Table 4-6 Encoder cable servo drive side connector
Connector exterior and terminal pin distribution
Motor
flange
Encoder pinout
40
60
80
