Wecon VD2 SA Series Servo Drives Manual (Lite V1.1)
WECON technology Co., Ltd
16
>20mm
>40mm
>40mm
>100mm
>100mm
>100mm
>100mm
>100mm
>100mm
FAN
F AN F AN
>20mm
CN2
CN1
Ch ar ge
CN2
CN1
Ch ar ge
CN2
CN1
Ch ar ge
Figure 3-7 Parallel installation dimensions of multiple VD2F drives
(3) Installation direction
When installing the servo drive, please face the front of the servo drive (panel control interface) to
the operator so that the servo drive is perpendicular to the wall.
