(3) Installation dimensions of 80 flange servo motor
1) WD series motor
Specification
WD series 80 flange motor
Rated torque (N.m)
2.39
LA without brake (mm)
98.5
LA with brake (mm)
132.5

19h6

-
0 0.013


20

70h7

-
0
0.03
25
2
3
35 ±0.5
± 1 LA
8
48 .10
53 .50
A
A



300±50
300±50
63 .6 4

80
4- 6 .40

90 ± 0 .1
6
21.50
M5
15
Motor line
Encoder line
A-A
Radio 1 :2
Standard oil seal
Plastic shell: 172167-1 (AMP)
Terminal pin: 170360-1 (AMP)
Plastic shell: 172169-1 (AMP)
Terminal pin: 170359-1 (AMP)
Figure 3-10 Installation dimension of WD series 80 flange motor
2) WE series motor
Specification
WE series 80 flange motor
Rated torque (N.m)
3.5
4.0
LA without brake (mm)
179
191
LA with brake (mm)
221
233
M5 L22×
70
19
-0.03
0
-0.021
0
15.5
-0.1
0
6
-0.03
0
25
3
35
8
LA
90
Φ
Φ
4-
80.4
80.4
6
Φ
Figure 3-11 Installation dimension of WE series 80 flange motor
