114 | CFW300
Appendix B / Anexo B
Appendix B
Anexo B
Table B2: Input and output currents, overload currents, carrier frequency, surrounding air temperature and
power losses specifications
Tabla B2: Especificaciones de corriente de salida y entrada, corrientes de sobrecarga, frecuencia de conmutación,
temperatura alrededor del convertidor y pérdidas
Tabela B2: Especificações de corrente de saída e entrada, correntes de sobrecarga, frequência de chaveamento,
temperatura ao redor do inversor e perdas
Inverter
Convertidor
Inversor
Output Rated Current
Corriente Salida Nominal
Corrente Nominal de
Saída
Overload Currents
Corrientes de Sobrecarga
Correntes de Sobrecarga
Rated Carrier Frequency
Frecuencia de
Conmutación Nominal
Frequência de
Chaveamento Nominal
Nominal Inverter
Surrounding
Temperature
Temperatura Nominal
Alrededor del
Convertidor
Temperatura Nominal
ao Redor do Inversor
Input Rated Current
Corriente de Entrada Nominal
Corrente Nominal de Entrada
Inverter Power
Losses
Perdidas del
Convertidor
Perdas do Inversor
Side-by-side IP20
IP20 Lado a Lado
IP20 Lado a Lado
Surface Mounting
Montaje en
Superfície
Montagem em
Superfície
(Inom) 1 min (fsw)
[Arms] [Arms] [kHz] [ºC / ºF] [Arms] [W]
CFW300A01P6S1NB20 1.6 2.4
5 50/122
7.1 30
CFW300A02P6S1NB20 2.6 3.9 11.5 45
CFW300A04P2S1NB20 4.2 6.3 18.6 60
CFW300A06P0S1NB20 6.0 9.0 26.5 75
CFW300A01P6S2NB20 1.6 2.4 3.5 30
CFW300A02P6S2NB20 2.6 3.9 5.7 35
CFW300A04P2S2NB20 4.2 6.3 9.2 50
CFW300A06P0S2NB20 6.0 9.0 13.2 75
CFW300A07P3S2NB20 7.3 11.0 16.1 90
CFW300A01P6T2NB20 1.6 2.4 1.9 30
CFW300A02P6T2NB20 2.6 3.9 3.1 35
CFW300A04P2T2NB20 4.2 6.3 5.0 50
CFW300A06P0T2NB20 6.0 9.0 7. 2 75
CFW300A07P3T2NB20 7.3 11.0 8.8 90
CFW300A01P6D3NB20 1.6 2.4 1.9 30
CFW300A02P6D3NB20 2.6 3.9 3.1 35
CFW300A04P2D3NB20 4.2 6.3 5.0 50
CFW300A06P0D3NB20 6.0 9.0 7.2 75
CFW300A07P3D3NB20 7.3 11.0 8.8 90
CFW300B10P0B2DB20 10.0 15.0 22.0/12.0 100
CFW300B15P2T2DB20 15.2 22.8 18.2 160
