7 ACCESSORIES
The accessories are hardware resources that can be added to the application. Thus, all models
can receive all the presented options.
The accessories are installed in the inverters easily and quickly using the "Plug and Play" concept.
The accessory must be installed or modified with the inverter power supply off. They may be
ordered separately, and will be shipped in individual packages containing the components and
the manuals with detailed instructions for the product installation, operation and programming.
The CFW300 inverters have two slots for simultaneous connection of the accessories:
Slot 1 - Communication accessory or external HMI (see Figure A3 on page 111).
Slot 2 - Input and output (I/O) expansion accessory (see Figure A4 on page 111).
Tabl e 7.1: Accessory models
WEG Item Name Description
Communication Accessories
13015223 CFW300-CRS485 RS-485 communication module
13014696 CFW300-CUSB USB communication module (2 m cable attached)
13 014674 CFW300-CRS232 RS-232 communication module
13014718 CFW300-CCAN CANopen and DeviceNet communication module
13015055 CFW300-CPDP Profibus DP communication module
13014672 CFW300-CBLT Bluetooth communication module
Input and Output (I/O) Expansion Accessory
13015050 CFW300-IOAR Input and output expansion module: 1 analog input, 1 analog output
and 3 relay outputs
13015051 CFW300-IODR Input and output expansion module: 4 digital inputs and 3 relay outputs
13015052 CFW300-IOAENC Input and output expansion module: 1 analog input, 2 analog outputs
and input for incremental encoder
13015054 CFW300-IOADR Input and output expansion module with remote control: 1 NTC input, 3
relay outputs and 1 input for infrared sensor (infrared sensor, NTC and
remote control with battery included)
External HMI
13014675 CFW300-KHMIR CFW300 remote HMI kit (CFW300-CRS485 + 3 m cable attached)
Flash Memory Module
13014693 CFW300-MMF Flash memory module (1 m cable attached)
RFI Filter Accessory
13015615 CFW300-KFA RFI filter kit CFW300 frame size A
13015616 CFW300-KFB RFI filter kit CFW300 frame size B
