- DIN Controllers & Indicators - Product Manual
59305, Issue 5 – March 2005 Specifications Page 133
Output Specifications
Output Module Types
Option Slot 1 Module Options:
Relay, SSR drive, Triac or DC linear.
Limit Controllers have a fixed Latching Relay only.
Option Slot 2 Module Options:
Relay, Dual Relay, SSR drive, Triac or DC linear.
Option Slot 3 Module Options:
Relay, SSR drive, DC Linear or Transmitter PSU.
1
/
8
DIN Indicators also support the Dual Relay option.
Specifications of Output Types
Contact Type: Single pole double throw (SPDT).
Control Rating: 2A resistive at 120/240V AC
Limit Controller output 1 has fixed 5A
latching relay.
Alarm, Event or EOP Rating: 2A resistive at 120/240V AC
Control/Alarm Lifetime: >500,000 operations at rated
voltage/current.
Limit Output Lifetime: >100,000 operations at rated
voltage/current.
Single Relay:
Isolation: Basic Isolation from universal input
and SSR outputs.
Contact Type: 2 x Single pole single throw (SPST)
with shared common.
Control Rating: 2A resistive at 120/240V AC
Control/Alarm Lifetime: >200,000 operations at rated
voltage/current.
Dual Relay:
Isolation: Reinforced safety isolation from inputs
and other outputs.
Drive Capability: 10V minimum at up to 20mA load.
SSR Driver:
Isolation: Not isolated from universal input or
other SSR driver outputs.
Operating Voltage Range: 20 to 280Vrms (47 to 63Hz).
Current Rating: 0.01 to 1A (full cycle rms on-state @
25°C); derates linearly above 40°C to
0.5A @ 80°C.
Max. Non-repetitive Surge
Current (16.6ms):
25A peak.
Min. OFF-State dv/dt @ Rated
Voltage:
500V/µs.
Max. OFF-State leakage @
Rated Voltage:
1mA rms.
Max. ON-State Voltage Drop @
Rated Current:
1.5V peak.
Repetitive Peak OFF-state
Voltage, Vdrm:
600V minimum.
Triac:
Isolation: Reinforced safety isolation from inputs
and other outputs.
