2 Installation
Unpacking
1. Remove the product from its packing. Retain the packing for future use, in case it is
necessary to transport the instrument to a different site or to return it to the supplier for
repair/testing.
2. The instrument is supplied with a panel gasket and push fit fixing strap. A single sheet
concise manual is also supplied in one or more languages. Examine the delivered items
for damage or defects. If any are found, contact your supplier immediately.
Installation
CAUTION:
Installation and configuration should be performed only by personnel who are
technically competent and authorised to do so. Local regulations regarding
electrical installation and safety must be observed.
Figure 1. Main dimensions
1
/
4
- DIN &
1
/
16
- DIN Instruments
1
/
8
- DIN Instruments
