WEST P4100 - 8 P6100, P8100 & P4100 Controller - Model Group

1
/
4
-DIN,
1
/
8
-DIN &
1
/
16
- DIN Controllers & Indicators - Product Manual
59305, Issue 5 – March 2005 Operating and Information Modes Page 37
8 P6100, P8100 & P4100 Controller – Model Group
These controllers combine technical functionality, field flexibility and ease of use to give you
the best in comprehensive process control. The P6100
1
/
16
–DIN Controller (48 x 48mm),
P8100
1
/
8
–DIN Controller (96 x 48mm) and P4100
1
/
4
–DIN Controller (96 x 96mm) offer
similar functionality in three DIN sizes.
• Heat/Cool operation
• Auto/Manual Tuning
• Two process alarms
• Ramping setpoint
• Loop alarm
• Remote or Dual setpoint selection
• RS485 Modbus and ASCII comms
• Configuration via PC
P6100, P8100 & P4100 Controllers - Configuration Mode
This mode is normally used only when the instrument is configured for the first time or when
a major change is made to the controller characteristics. The Configuration Mode parameters
must be set as required before adjusting parameters in Setup Mode, or attempting to use the
instrument in an application.
Entry into the Configuration Mode
CAUTION:
Adjustments to these parameters should only be performed by personnel
competent and authorised to do so.
Configuration is entered from Select Mode
Hold down and press to force the controller into the Select Mode.
then
Press or to navigate to the Configuration Mode option, then press .
Note:
Entry into this mode is security-protected by the Configuration Mode Lock Code. Refer to
the Unlock Code section for more details.
Scrolling through Parameters and Values
Press to scroll through the parameters (parameters are described below).
Note:
Only parameters that are applicable to the hardware options chosen will be displayed.
