Page 62 P6700, P8700& P4700 Model Group 59305, Issue 5 – March 2005
P6700, P8700 & P4700 Limit Controllers – Setup Mode
This mode is normally selected only after Configuration Mode has been completed, and is
used when a change to the process set up is required.
Note:
Entry into Setup Mode is security-protected by the Setup Mode lock code.
Entry into the Setup Mode
Hold down and press to enter the Select Mode
Press or to navigate to the Setup Mode option, then press to enter
Setup Mode.
The Setup LED will light while in Setup mode
Scrolling through Parameters & Values
Press to scroll through the parameters (refer to the table below) and their values.
Changing Parameter Values
Press to select the required parameter, then press or to set the value as
required.
Once the displayed value is changed, the effect is immediate. No confirmation of the
change is required.
Note:
If there is no key activity for two minutes, the instrument returns to the operator mode.
