- DIN Controllers & Indicators - Product Manual
59305, Issue 5 – March 2005 P6100, P8100 & P4100 Model Group Page 47
Parameter Lower
Display
Upper Display
Adjustment Range
Default
Value
When
Visible
Setpoint Value
:-'
Within scale range upper
and lower limits
Range
minimum
Always
Local Setpoint Value
+:-'
B+:-
or
*+:-
Within scale range upper
and lower limits.
B or
* before the legend
indicates if this is the
currently active SP
Range
minimum.
,1%5 or
,1%6 = 9:-<
Setpoint 1 Value
:-2'
B:-2
or
*:-2
Within scale range upper
and lower limits.
B or
* before the legend
indicates if this is the
currently active SP
Range
minimum.
D<!< or
D<!3 = D<:2
Setpoint2 Value
:-3'
B:-3
or
*:-3
Within scale range upper
and lower limits.
B or
* before the legend
indicates if this is the
currently active SP
Range
minimum.
D<!< or
D<!3 = D<:2
Set-up Lock Code
:+"?'
0 to 9999
2@'
Always
**First Operator mode displays follows.
Note:
Alarm parameters marked * are repeated in Configuration Mode.
Note:
**Once the complete list of Set Up Mode parameters has been displayed, the first
Operator Mode display is shown without exiting from Set Up Mode. Display seen is
dependant on the Display Strategy and status of Auto/Manual mode selection.
P6100, P8100 & P4100 Controllers - Operator Mode
This is the mode used during normal operation of the instrument. It can be accessed from
Select Mode, and is the usual mode entered at power-up. The available displays are
dependent upon whether Dual or Remote Setpoint modes are being used, whether Setpoint
Ramping is enabled and the setting of the Display Strategy parameter in Configuration Mode.
WARNING:
IN NORMAL OPERATION, THE OPERATOR MUST NOT REMOVE THE CONTROLLER FROM
ITS HOUSING OR HAVE UNRESTRICTED ACCESS TO THE REAR TERMINALS, AS THIS
WOULD PROVIDE POTENTIAL CONTACT WITH HAZARDOUS LIVE PARTS.
CAUTION:
Set all Configuration Mode parameters and Set Up Mode parameters as required
before starting normal operations.
To Next Page
