WEST P4100 - Figure 8. Option Module Connectors

1
/
4
-DIN,
1
/
8
-DIN &
1
/
16
- DIN Controllers & Indicators - Product Manual
Page 10 Plug-in Options 59305, Issue 5 – March 2005
Figure 8. Option Module Connectors -
1
/
8
&
1
/
4
DIN Instruments
CAUTION:
Check for correct orientation of the modules and that all pins locate correctly into
the socket
Option Slot 2
Connector PL4A
Option Slot A
Connectors PL5 & PL6
Option Slot B
Connectors PL2A,
PL2B & PL2C
Option Slot 3
Connectors PL4B
Option Slot 1
Connectors PL7 & PL8
