WEST P4100 - Figure 25. Option Slot 2 - Dual Relay Module; Figure 26. Option Slot 2 - Linear Voltage & Madc Module; Option Slot 2 - Dual Relay Module; Option Slot 2 - Linear Voltage or Madc Module

1
/
4
-DIN,
1
/
8
-DIN &
1
/
16
- DIN Controllers & Indicators - Product Manual
59305, Issue 5 – March 2005 Connections Page 23
Option Slot 2 - Dual Relay Module
If option slot 2 is fitted with a dual relay output module, make connections as illustrated. This
module has two independent relays, which share a common connection terminal. The
contacts are rated at 2 amp resistive 120/240 VAC.
1
/
16
DIN
1
/
4
DIN &
1
/
8
DIN
Figure 25. Option Slot 2 - Dual Relay Module
WARNING:
THIS MODULE MUST NOT BE FITTED INTO OPTION SLOT 3 ON
1
/
16
DIN INSTRUMENTS.
Option Slot 2 - Linear Voltage or mADC module
If option slot 2 is fitted with a DC linear output module, make connections as illustrated.
1
/
16
DIN
1
/
4
DIN &
1
/
8
DIN
Figure 26. Option Slot 2 - Linear Voltage & mADC module
22
23
_
24
+
13
14
+
15
_
22
23
N/O OUTPUT 4
COMMON
24
N/O OUTPUT 2
13
14
N/O OUTPUT 2
COMMON
15
N/O OUTPUT 4
