WEST P4100 - Standards; Physical Specifications

1
/
4
-DIN,
1
/
8
-DIN &
1
/
16
- DIN Controllers & Indicators - Product Manual
Page 136 Specifications 59305, Issue 5 – March 2005
Standards
Conformance Norms:
CE, UL, ULC.
EMC standards:
EN61326*
Safety Standards:
EN61010 and UL3121.
Also FM 3545, 1998 for Limit Controllers.
Front Panel Sealing:
IP66
Note:
*For disturbances induced by RF fields of 10V/m 80% AM at 1kHz the input accuracy
specification is changed to 0.25% in the frequency bands 465 to 575 MHz and 630 to 660
MHz.
Physical Specifications
Dimensions: Depth behind
panel:
110mm (
1
/
16
DIN instruments).
100mm (
1
/
8
&
1
/
4
DIN instruments).
Front bezel
size (w x h):
48 x 48mm (
1
/
16
DIN instruments).
48 x 96mm (
1
/
8
DIN controllers).
96 x 48mm (
1
/
8
DIN indicators).
96 x 96mm (
1
/
4
DIN instruments).
Mounting:
Plug-in with panel mounting fixing strap.
Panel cut-out size (w x h)::
45mm x 45mm (
1
/
16
DIN instruments).
45 x 92mm (
1
/
8
DIN controllers).
92 x 45mm (
1
/
8
DIN indicators).
92mm x 92mm (
1
/
4
DIN instruments).
Terminals:
Screw type (combination head).
Weight:
0.21kg maximum.
