WEST P4100 - Table 1. Option Module Vs. Model Matrix

1
/
4
-DIN,
1
/
8
-DIN &
1
/
16
- DIN Controllers & Indicators - Product Manual
59305, Issue 5 – March 2005 Plug-in Options Page 7
Table 1. Option Module vs. Model Matrix
MODEL NUMBER
MODULE PART
NUMBER
& Function
P6100 P8100 P4100 P6700 P8700 P4700 P6010 P8010
OPTION
SLOT 1
PO1-C10
Relay
PO1-C50
SSR Driver
PO1-C80
Triac
PO1-C21
Linear mA/V DC
OPTION
SLOT 2
PO2-C10
Relay
PO2-C50
SSR Driver
PO2-C80
Triac
PO2-C21
Linear mA/V DC
PO2-W09
Dual Relay
OPTION
SLOT 3
PO2-C10
Relay
PO2-C50
SSR Driver
PO2-C21
Linear mA/V DC
PO2-W08
TransmitterPSU
PO2-W09
Dual Relay
OPTION
SLOT A
PA1-W06
RS485 Comms
PA1-W03
Digital Input
PA1-W04
Basic RSP Input
OPTION
SLOT B
PB1-W0R
Full RSP Input
SOFTWARE &
ACCESSORIES
PS1-CON
Config Software
KEY
Option Possible
Option Not Possible
