1
/
4
-DIN,
1
/
8
-DIN &
1
/
16
- DIN Controllers & Indicators - Product Manual
Page 138 Model Codes 59305, Issue 5 – March 2005
Model Code Pxxxx -x-x-x-x-x-x-x- x - x - x - Sxxx
Option Slot 3
Not fitted
0
Relay Output
1
DC Drive Output for SSR
2
Linear 0-10V DC Output
3
Linear 0-20mA DC Output
4
Linear 0-5V DC Output
5
Linear 2-10V DC Output
6
Linear 4-20mA DC Output
7
Transmitter PSU
8
Dual Relay Outputs (
1
/
8
DIN indicators only)
9
Option Slot A**
Not fitted
0
RS-485 Serial Communications
1
Digital Input 1
3
Remote Setpoint Input (Basic)
4
Supply Voltage
100-240V AC
0
24-48V AC or DC
2
Display Colour
Red Display (single display) or Red/Red (dual display)
0
Green Display (single display) or Green/Green (dual display)
1
Red Upper/Green Lower Display (dual display only)
2
Green Upper/Red Lower Display (dual display only)
3
Colour Change Single Display (Red/Green)
4
Option Slot B (
1
/
8
&
1
/
4
DIN instruments only) ***
Not fitted
0
Remote Setpoint Input (Full) with Digital Input 2
R
Manual Language
No Manual
0
English
1
French
2
German
3
Italian
4
Spanish
5
Mandarin
6
English/French/German/Italian/Spanish - Concise Manuals only 9
** Slot A Basic RSP must not be installed if Slot B Full RSP is fitted.
*** Slot B is only available on
1
/
8
&
1
/
4
DIN controllers. This code position
is blank for other instruments
continued on
next page….
