WEST P4100 - Page 77

1
/
4
-DIN,
1
/
8
-DIN &
1
/
16
- DIN Controllers & Indicators - Product Manual
Page 58 P6700, P8700& P4700 Model Group 59305, Issue 5 – March 2005
Parameter Lower
Display
Upper
Display
Description Default
Value
When
Visible
/$'
N type: 0 to 1399 ºC
/&'
N type: 32 to 2551 ºF
9$'
R type: 0 to 1759 ºC
9&'
R type: 32 to 3198 ºF
:$'
S type: 0 to 1762 ºC
:&'
S type: 32 to 3204 ºF
#$'
T type: -240 to 400 ºC
#&'
T type: -400 to 752 ºF
#. $
T type: -128.8 to 400.0 ºC
with decimal point
#. &
T type: -199.9 to 752.0 ºF
with decimal point
-3E$'
PtRh20% vs PtRh40%:
0 to 1850 ºC
-3E&'
PtRh20% vs PtRh40%:
32 to 3362 ºF
-K$'
Pt100: -199 to 800 ºC
-#&'
Pt100: -328 to 1472 ºF
-#. $
Pt100: -128.8 to 537.7 ºC
with decimal point
-#. &
Pt100: -199.9 to 999.9 ºF
with decimal point
@B3@'
0 to 20mA DC
EB3@'
4 to 20mA DC
@BG@'
0 to 50mV DC
2@. G@'
10 to 50mV DC
@BG'
0 to 5V DC
2BG'
1 to 5V DC
@B2@'
0 to 10V DC
'
3B2@'
2 to 10V DC
Scale Range
Upper Limit
9=+'
Scale Range Lower Limit +100 to Range
Max
Linear
inputs =
1000
(°C/°F
inputs =
max
range)
Always
Scale Range
Lower Limit
9++'
Range Min. to Scale range Upper Limit -
100
Linear = 0
(°C/°F =
min range)
Always
