System Operating System Embedded Linux 2.6
Video
Input 9 / 16
Main monitor VGA / BNC / HDMI / S-Video
Detection Motion, Video loss
Audio Input / Output 4 In, 2 Out
Record
Compression H.264 Video, ADPCM Audio
Frame rate (FPS) & Resolution
NTSC 120 / 720*480, 240 / 720*240, 270 / 360*240
(9CH), 480 / 360*240 (16CH)
PAL 100 / 720*576, 200 / 720*288, 400 / 360*288 (16CH)
Watermark Yes
Mode Manual / Schedule / Alarm / Motion
Pre-record 0 - 60 seconds
Post-record 0 - 60 minutes
Display
Resolution NTSC – 720*480, PAL – 720*576
Frame rate Up to 30 NTSC, 25 PAL FPS per display window
Digital Zoom X2, X4
Playback
Frame rate (FPS) & Resolution
NTSC 120 / 720*480, 240 / 720*240, 270 / 360*240
(9CH), 480 / 360*240 (16CH)
PAL 100 / 720*576, 200 / 720*288, 400 / 360*288 (16CH)
Search
Smart search, Date/time, Camera, Alarm, Motion, &
Video Loss
Storage
SATA HDD
1 - 500gb (9ch) / 1 - 1TB (16ch) with
expansion for up to 4 total if DVD and ESATA
connectors used
USB Ports 2
Alarm Input / Output 16 / 2 NO, 2 NC
Network
Ethernet 1 RJ-45 10/100Mbps
Web
Internet Explorer 32bit with Windows 7, Vista, XP,
and 2000 / Video Streaming
E-mail / FTP Yes
Two-way Audio Yes
Remote users 6
Remote stations
PC (Windows / Internet Explorer), iPhone
®
(native), Android
Control Port
RS-232 1 DSUB for Automation Control
RS-485 1 Screw Terminal for Keyboard and PTZ
Setup
Local I/R remote, USB mouse
Remote Windows Application and Internet Explorer 32bit
Multi-lingual Yes
Weights & Measures
Dimension
16.9” x 12.9” x 3.4“
2U with Rack Mount Ears Included
Weight 11 lbs (w/o HDD)
Power
Source 12VDC 8.33A (External)
Consumption 110W Max.
Operating Temperature 32° ~ 113°F
11. APPENDIX A – SPECIFICATIONS
Specications are subject to change without notice
