Wirepath WPS-300-DVR - Default Chapter; Table of Contents

TABLE OF CONTENTS
1. PRODUCT OVERVIEW 5
1.1. INTRODUCTION 5
1.2. PACKING LIST 5
1.3. FEATURES 5
2. FRONT AND REAR PANELS AND REMOTE CONTROL 6
2.1. FRONT PANEL 6
2.2. REAR PANEL 8
2.3. REMOTE CONTROL 10
3. INSTALLATION 11
3.1. POSITIONING THE 300 DVR 11
3.1.1. RACK MOUNTING THE 300 SERIES DVR 11
3.2. CONNECTIONS 12
3.2.1. BASIC CONNECTIONS 12
3.2.2. OPTIONAL CONNECTIONS 12
3.2.3. PTZ CAMERA / AUTOMATION SYSTEM CONNECTIONS 13
4. MAIN SCREEN AND BASIC OPERATIONS 15
4.1. TEXT INPUT 16
4.2. LOGIN / LOGOUT 17
4.3. BASIC OPERATIONS USING THE CONTROL BAR 17
4.4. DIGITAL ZOOM 19
5. MAIN MENU 20
5.1. STATUS DISPLAY 20
5.2. VOLUME CONTROL 21
5.3. VIDEO ADJUSTMENT 22
5.4. DISPLAY 23
5.5. BACKUP DEVICE 24
5.6. SOFTWARE UPGRADE 25
5.6.1. UPDATING SOFTWARE VIA DVR LOCAL DISPLAY 25
5.7. SYSTEM SHUTDOWN 26
6. SETUP MENU 27
6.1. PRE-CAMERA SETUP 28
6.2. CAMERA SETUP 29
6.2.1. VIDEO LOSS SETUP 31
6.2.2. MOTION SETUP 33
6.2.2.1. DETECTION SETTINGS 35
6.3. ALARM SETUP 36
6.4. SEQ DISPLAY SETUP 38
6.5. SCHEDULED RECORD SETUP 40
6.6.1. SCHEDULED RECORD – EASY SETUP 41
6.7. HDD SETUP 43
6.7.1. HDD FORMAT/CLEAR 45
6.7.2. ADVANCED HDD SETUP 46
6.8. PASSWORD SETUP 48
6.8.1. ADVANCED USER SETUP 50
6.9. SYSTEM SETUP 52
6.10. COMMUNICATION PROTOCOL SETUP 54
6.11. NETWORK SETUP 56
6.11.1. E-MAIL SETUP 57
6.11.2. FTP SETUP 59
6.11.3. ADVANCED NETWORK SETUP 60
6.12. FACTORY DEFAULT 61
7. PTZ CONTROL 62
7.1. OSD CONTROL FOR WIREPATH™ SURVEILLANCE CAMERAS 63
8. SEARCH/PLAYBACK/ARCHIVE 65
8.1. SEARCH BY TIME 66
8.2. SEARCH BY EVENT / LOG DISPLAY 67
8.3. SMART SEARCH 69
8.4. SEARCH ARCHIVED FILES 71
8.5. PLAYBACK SEARCH RESULTS 72
8.6. ARCHIVE (BACKUP) SEARCH RESULTS 73
