1-6
Chapter 1: Introduction and Features
Aug 2012
Temperature
Guidelines
Units which are stored at below room temperature are required to acclimate to room temperature
before powering on. This avoids rapid thermal increase, potential for thermal shock, and avoids
excessive condensation.
Lock
Specifications/
Guidelines
This section contains CPU and Cabinet entry lock specifications.
CPU Lock
Specifications
Reference Table 1-2 and Table 1-3 for the lock specifications on the CPU Assembly Door.
Table 1-2 CPU Lock Specs (in inches).
Table 1-3 CPU Lock Specs (in millimeters).
G CompactFlash Drive (OS software) J12
H CompactFlash Drive (game software) J10
I Jurisdictional SPI EPROM XU4
J Digital Audio (SPDIF) Connector J2
K BIOS XU1
L DVI Primary Video Port
DVI Secondary DVI Port
J1 Top
J1 Bottom
M Battery 1 for NVRAM subsystem BH1/BAT1
Battery 2 for NVRAM subsystem BH2/BAT2
N Serial Video Port
VGA Analog Video Port
J3 Top
J3 Bottom
O 10/100/1000 Mbit/s Ethernet/+ 2 USBs J7
P 10/100/1000 Mbit/s Ethernet/+ 2 USBs J6
Q SSD J13 and J15
Table 1-1 Layout of CPU-NXT 3.2.
ID Connector Connector Position
Lock Location
Designed
Length (inches)
Extended
Length*
Cam
Description
Cam Part No.
Rotation to
Lock (viewed
from key end)
CPU Assembly 5/8 inches (.625) 1/2 inches (.5)
outside
Special 01-027230-00-00 clockwise
CPU Assembly
(secondary)
5/8 inches (.625) 1/2 inches (.5)
outside
1 1/4 inches
(1.25) flat
01-12793-08 clockwise
Lock Location
Designed
Length (mm)
Extended
Length*
Cam
Description
Cam Part No.
Rotation to
Lock (viewed
from key end)
CPU Assembly 16 mm 13 mm outside Special 01-027230-00-00 clockwise
CPU Assembly
(secondary)
16 mm 13 mm outside 32 mm flat 01-12793-08 clockwise
* Conditions
Extending the lock inside requires a new cam.
Extending the lock outside requires a spacer.
