6. Remove electronic cover
plate on the right side of
the treadmill frame.
Fig. 42 Mercury/Path assembly, electronic cover plate
7. Pull wire and protective
cover out of the railing tube
(hole in railing tube).
Fig. 43 Mercury/Path assembly, connection 1
8. Lay the wire with protective
cover through the hole in
the console.
Fig. 44 Mercury/Path assembly, connection 2
