Properties
Xerox CopyCentre/WorkCentre 118 User Guide 107
Port Settings This page displays the port settings for your machine, for
example, Ethernet and Parallel. Port Settings allows you to
configure the settings. Items displayed on this page will
depend on the model and settings of your printer.
Ethernet
This page allows you to configure the Ethernet transmission
rate.
Ethernet Settings – You can select one of the following
options.
• Auto: Detects the Ethernet transmission rate
automatically.
• 100BASE-TX: Selects 100BASE-TX as the default value.
• 10BASE-T: Selects 10BASE-T as the default value.
MAC Address – This is a display-only item.
Parallel
This page allows you to configure the parallel port settings.
Bi-directional Communication – Enable or disable
bidirectional communication (IEEE1284).
Auto Eject Time – Specifies the time when the paper will be
automatically ejected if no data is sent to the printer.
Adobe Communication Protocol – This is only displayed
when PostScript is enabled. Select one of the following
options.
• Normal: Select this when the communication protocol is in
the ASCII format.
• Binary: Select this when the communication protocol is in
the binary format.
• TBCP: Select this to switch between the specific control
codes when the communication protocols involve both
ASCII and binary formats.
USB
This page allows you to configure the USB settings.
Auto Eject Time – Specifies the time when the paper will be
automatically ejected if no data is sent to the printer.
Adobe Communication Protocol – This is only displayed
when PostScript is enabled. Select one of the following
options.
• Normal: Select this when the communication protocol is in
the ASCII format.
• Binary: Select this when the communication protocol is in
the binary format.
• TBCP: Select this to switch between the specific control
codes when the communication protocols involve both
ASCII and binary formats.
Feature name Setting items
