Xerox Phaser 3100MFP Service Manual

Parts List
Phaser 3100 MFP 04/08 5-7
PL 3 Paper Exit and Rear Cover
ITEM No. REFERENCE DESCRIPTION QTY R
1 038N00521 Guide papier sortie imprimante
Exit paper guide
2
2 Not spared VIS 3x10 self tapping screw for plastic Screw 3x10
Self tapping screw for plastic
2
3 002N02745 Capot arrière imprimante LFX V2 coloré
Lower rear cover
1 REP 13
4 002N02746 Trappe arrière
Upper rear cover
1 REP 13
5 Not spared Imprimante
Machine
1
6 050N00522 Tirette imprimante + extension
Tray exit+ extend
1
7 050N00525 Interface équipée Gray White V2 (voir planche 4)
Output tray assembly (refer to PL 4
)
1 REP 14
8 Not spared Vis autar. M3x6 steel swch16A
Screw M3x6 steel
6
