Xerox Phaser 3100MFP Service Manual

Parts List
Phaser 3100 MFP 04/08 5-1
5 Parts List
PL 1 Controls and Cables ........................................................................................................ 5-2
PL 2 Covers .............................................................................................................................. 5-4
PL 3 Paper Exit and Rear Cover .............................................................................................. 5-6
PL 4 Output Tray Assembly ..................................................................................................... 5-8
PL 5 Scanner .......................................................................................................................... 5-10
PL 6 CIS Support ................................................................................................................... 5-12
PL 7 Automatic Document Feeder (3100MFP/X only) (1 of 3) ............................................... 5-14
PL 8 Automatic Document Feeder (3100MFP/X only) (2 of 3) ............................................... 5-16
PL 9 Automatic Document Feeder (3100MFP/X only) (3 of 3) ............................................... 5-18
PL 10 Paper Tray ................................................................................................................... 5-20
PL 11 Rollers and Drives ........................................................................................................ 5-22
PL 12 Fuser ............................................................................................................................ 5-24
PL 13 Power Supply and Laser Unit ...................................................................................... 5-26

Xerox Phaser 3100MFP Specifications

General

Print Technology	Laser
Copy Resolution	600 x 600 dpi
Standard Paper Capacity	250 sheets
ADF Capacity	50 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Duplex Printing	Manual
Paper Capacity	250 sheets
Supported Operating Systems	Windows, Mac OS, Linux
Print Resolution	1200 x 1200 dpi
Scan Resolution	600 x 600 dpi
Copy Speed (Black)	20 cpm
Print Speed	Up to 20 ppm
