Repairs and Adjustments
Phaser 3100 MFP 04/08 4-39
REP 15 Machine Disassembly
Parts List on: PL 2
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Preparation
• None.
Removal
1. Stand in front of the machine.
2. Remove the control panel REP 1
.
3. Remove the ADF cover (REP 2
) or the platen cover (REP 38).
4. Remove the front door and the side covers (REP 3).
5. Remove the CPU module (REP 11) and the speaker (REP 12).
6. Remove the platen assembly (REP 16).
7. Remove the back cover (REP 13) and the output tray assembly (REP 14).
Replacement
1. Replacement is the reverse of the removal procedure.
To Next Page
