Xerox Phaser 3100MFP Service Manual

Repairs and Adjustments
Phaser 3100 MFP 04/08 4-65
REP 27 Fusing Lamp and Heat Roller
Parts List on: PL 12
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
WARNING
Do not touch the fuser while it is hot.
Preparation
• Remove the paper exit assembly, REP 26.
• Remove the fuser, REP 25
