Repairs and Adjustments
4-66 04/08 Phaser 3100 MFP
Removal
Fusing Lamp
1. Release the fusing lamp, Figure 1.
CAUTION
Do not touch the surface of the fusing lamp with bare hands. Take care when removing the lamp,
it can break if not handled with care.
Figure 1
1
Remove 2 screws,
1 at each end of the fusing lamp
