Repairs and Adjustments
4-70 04/08 Phaser 3100 MFP
REP 28 Pressure Roller
Parts List on: PL 12
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
WARNING
Do not touch the fuser while it is hot.
Preparation
• Remove the paper exit assembly, REP 26.
• Remove the fusing lamp and hot roller, REP 27.
To Next Page
