Repairs and Adjustments
Phaser 3100 MFP 04/08 4-71
Removal
1. Remove the pressure roller, Figure 1.
CAUTION
Note the position of the bushing and spring at each end of the roller.
Figure 1
Pressure roller
Bushing and spring at each side
