Parts List
Phaser 3100 MFP 04/08 5-13
PL 6 CIS Support
ITEM No. REFERENCE DESCRIPTION QTY R
1 117N01798 Nappe CIS 12 points 50 microns
12 pin 50 micrometers CIS flat cable
1 REP 20
2 117N01797 Ferrite p.cable plat 3W800 10 cond. SP
Ferrite p.cable plat 3W800 10 cond. SP
1
3 Not spared Guidage central chariot CIS coloré
Central roller of CIS support colored
2
4 Not spared CIS support coloré
CIS support colored
1
5 Not spared Guidage latéral chariot CIS coloré
Lateral roller of CIS support colored
3
6 Not spared Connecteur courroie CIS
CIS drive belt connection
1
7 Not spared Ressort courroie
CIS belt spring
1
8 Not spared Courroie
CIS drive belt
1
