Repairs and Adjustments
Phaser 3435 5/08 4-9
2. Remove the four screws securing the Rear Cover and then Release the Rear Cover from the
machine.
Figure 2
3. To remove the Face Up Cover, first release the Stopper Strap in the direction of arrow.
Figure 3
Rear cover
Stopper strap
