Parts List
Phaser 3435 5/08 5-3
PL 1 Main Parts List
No. Part No. Description QT’y Remark
5.1-0 - MACHINE
5.1-1 - ELA HOU-FRAME 220V 1
5.1-1 - ELA HOU-FRAME 110V 1
5.1-2 007N01561 ELA UNIT-MAIN DRIVE 1
5.1-3 002N02783 ELA HOU-MPF 1
5.1-6 127N07328 FAN-DC 1 REP 14
5.1-7 127N07485 FAN-DC 1 REP 14
5.1-8 - ELA UNIT-FUSER DRIVE 1
5.1-9 - MEA-SHIELD CONTROLLER 1 REP 8
5.1-10 - SHEET-INSULATOR_PBA 1 REP 8
5.1-11 140N63345 PBA MAIN-CONTROLLER 1 REP 8
5.1-12 - CBF HARNESS-LCD_OPE 1
5.1-13 002N02628 MEA-TRANSFER ROLLER 1
5.1-13-1 - ROLLER-TRANSFER 1
5.1-13-2 - GEAR-TRANSFER 1
5.1-14 122N00259 UNIT-LSU 1 REP 23
5.1-15 - MEA-COVER 1
5.1-16 - ELA UNIT-INITIAL DEVE (CARTRIDGE-PRINT) 1
5.1-17 050N00535 MEA UNIT-CASSETTE 1
5.1-24 - CBF HARNESS-EXIT MTR 1
5.1-25 - CBF HARNESS-MAIN MTR 1
5.1-26 101N01422 MEA UNIT-DUPLEX 1
5.1-27 - SHIELD-P-SMPS 1 REP 11
5.1-28 - CBF HARNESS-AC INLET 1
5.1-29 - CABLE CLAMP 3
5.1-30 - SHEET-INSULATOR_SMPS 1 REP 11
5.1-31 112N00229 SMPS (220V) 1 REP 11
5.1-31 112N00228 SMPS (110V) 1 REP 11
5.1-32 117N01769 CBF-POWER CORD(220V) 1
5.1-32 105N02072 CBF-POWER CORD(110V) 1
5.1-33 - CABLE CLAMP 3
5.1-34 - ELA UNIT-DUPLEX DRIVE 1 REP 10
097N01539 OPTIONAL TRAY (NOT SHOWN) 1
144N00159 OPTIONAL MEMORY (128Mb) (NOT SHOWN) 1
144N00139 OPTIONAL MEMORY (256Mb) (NOT SHOWN) 1
