Parts List

Phaser 3435 5/08 5-15

PL 7 Frame (2 of 3)

No. Part No. Description QT’y Remark

5.6-11 - SHAFT-M_FEED2 1

5.6-12 - GEAR-FEED2 Z27 1

5.6-13 - RING-E 1

5.6-14

PMO-BUSHING FEED 3

5.6-15 022N02080 ROLLER-FEED ROLLER 1 1 REP 20

5.6-17 - PMO-LOCKER CST 2

5.6-18 - SPRING-TS 1

5.6-19 - CAM-M-PICK_UP 1

5.6-20 - RING-CS 1

5.6-21 - SOLENOID-MANUAL 1 REP 21

5.6-22 - SOLENOID-FEED 1 REP 21

5.6-23 - GROUND-P-DRIVE 1

5.6-24 - GROUND-P-PUSH BUSHING 1

5.6-25 - GROUND-P-DRIVE2 1

5.6-26 - CABLE CLAMP 1

5.6-27 - SPRING ETC-GUIDE DEVE 2

5.6-28 - PMO-PLATE GUIDE DEVE_L 1

5.6-29 - PMO-PLATE GUIDE DEVE_R 1

5.6-30 - GROUND-P-SHIELD 1

5.6-31 - TERMINAL-P_CRUM 4

5.6-32 - HOLDER-BEARING EXIT F/DOWN 2

5.6-33 022N02081 MEA RACK-EXIT ROLLER 1 REP 22

5.6-34 - ROLLER-EXIT F/DOWN 1

5.6-35 - PBA SUB-TERMINAL 1 REP 24

5.6-36 022N02081 MEA RACK-EXIT ROLLER 4

5.6-36-1 - PMO-ROLLER FD R 1

5.6-36-2 - PMO-ROLLER FD F 1

5.6-36-3 - PMO-HOLDER EXIT ROLL 1

5.6-36-4 - SPRING ETC-EXIT ROLL FD 1
