Xerox PHASER 3435 - Page 171

Parts List
Phaser 3435 5/08 5-17
PL 8 Frame (3 of 3)
No. Part No. Description QT’y Remark
5.6-39 - GROUND-P-FUSER 1
5.6-40 - GROUND-P-MOTOR FUSER 1
5.6-41 - GROUND-P-SHIELD SMPS 1
5.6-42 - GROUND-P-GUIDE TR 1
5.6-43 - MEC-TERMINAL 4
5.6-43-1 - SPRING ETC-HV APOLLO 1
5.6-43-2 - IPR-TERMINAL 1
5.6-44 - TERMINAL-P-HV CR
5.6-45 - IPR-P-TERMINAL CON 1
5.6-46 - HOUSING-M_TERMINAL 3
5.6-47 - PBA-CONNECTION 1 REP 12
5.6-48 - PMO-ACTUATOR CVR OPEN 1
5.6-49 - GUIDE-TR RIB 1
5.6-50 - PLATE-E_SAW 1
5.6-51 - GUIDE-P-TR 1
5.6-53 - SPRING ETC-TR 2
5.6-54
- PLATE-P-PUSH BUSHING 2
5.6-55 - HOLDER-M-PTL R2 1
5.6-56 - IPR-P-EARTH TRANSFER 1 REP 25
5.6-57 - SPRING ETC-TR L HAWK 1
5.6-58 - BUSH-M-TR L 1
5.6-59 - PMO-BUSHING_TR(L) 1
5.6-60 - GROUND-P-EARTH TR 1
5.6-61 - ELA UNIT-FUSER(220V) 1
5.6-61 - ELA UNIT-FUSER(110V) 1
5.6-62 - FOOT-BACK 2
5.6-63 - SPRING-TS 3
5.6-64 - HOLDER-M_ACT REGI 1
5.6-65 - LEVER-M_ACTUATOR REGI 1
5.6-66 - LEVER-M_ACT DUP OUT 1
5.6-67 - HOLDER-M_ACT FEED 1
5.6-68 - SPRING-TS 3
5.6-69 - CBF HARNESS-LSU S/W 1
5.6-70 - SHIELD-P-HVPS 1 REP 17
5.6-71 - SHEET-INSULATOR_HVPS 1 REP 17
5.6-72 112N00230 HVPS 1 REP 17
5.6-73 - CBF HARNESS-SMPS 1
5.6-74 - CBF HARNESS-ENGINE 1
5.6-75 - CBF HARNESS-PAPER EMP 1
5.6-76 - PLATE-LSU SUPPORT 1
