Parts List
Phaser 3435 5/08 5-19
PL 9 MP Assembly
No. Part No. Description QT’y Remark
5.9-0 - ELA HOU-MPF 1 REP 19
5.9-1 - FRAME-M_MP 1
5.9-2 - MEA-IDLE FEED 1
5.9-2-1 - HOLDER-M_IDLE FEED 1
5.9-2-2 - SPRING ETC-EXIT LOWER IDLE 2
5.9-2-3 - HOLDER-M_SHAFT IDLE 2
5.9-2-4 - ROLLER-IDLE FEED 1
5.9-2-5 - SHAFT-IDLE FEED 1
5.9-2-6 - COVER-M_IDLE FEED 1
5.9-3 - SHEET-GUIDE MP 1
5.9-4 - GEAR-IDLE 23 1
5.9-5 121N01173 SOLENOID-MP 1
5.9-6 - HOLDER-M-PAD_MP 1
5.9-7 019N00742 RPR-FRICTION PAD 1
5.9-8 - SPRING ETC-EXIT ROLL FD 1
5.9-9 - PLATE-P-KNOCK UP_MP 1
5.9-10 - PMO-ROLLER CAM.MP 1
5.9-11 - RPR-PAD CASSETTE 1
5.9-12 - SPRING-ES 2
5.9-13 - HOLDER-M-SENSOR_MP 1
5.9-14 - PHOTO-INTERRUPTER 1
5.9-15 - PMO-M-ACT EMPTY MP 1
5.9-16 - CBF HARNESS-MPF SEN 1
5.9-17 130N01366 MEA-PICK UP_MP 1 REP 19
5.9-17-1 130N01534 RUBBER-PICK UP MP 1
5.9-17-2 - HOUSING-M_PICK UP_MP 1
5.9-17-3 - HOUSING-M-PICK UP2_R2 1
5.9-18 - GEAR-M-PICK UP_MP 1
5.9-19 - SPRING-CS 1
5.9-20 - GEAR-M-HOLDER_MP 1
5.9-21 - CAM-M_PICK UP MP 1
5.9-22 - SHAFT-P-PICK_UP 1
5.9-23 - STOPPER-M-PICK UP_R2 2
5.9-24 - PMO-IDLE PICK_UP 2
5.9-25 - SHAFT-P-CORE 2
5.9-26 - BUSH-M-PICK_UP R 1
5.9-27 - BRACKET-P-PICKUP_MP 1
To Next Page
