Parts List
Phaser 3435 5/08 5-27
PL 13 Fuser Unit (1 of 2)
No. Part No. Description QT’y Remark
5.13-0 126N00291 ELA UNIT-FUSER (110V) 1 REP 4
5.13-0 126N00290 ELA UNIT-FUSER (220V) 1 REP 4
5.13-1 - COVER-FUSER_UPPER 1
5.13-2 - GEAR-EXIT 1
5.13-3 022N02365 ROLLER-PRESSURE 1
5.13-4 022N02301 ROLLER-PRESSURE 1
5.13-5 022N02366 ROLLER-HEAT 1
5.13-6 - BUSH-HR_R 2
5.13-7 - GEAR-FUSER 1
5.13-8 - BEARING-BALL 2
5.13-9 - SPRING-TS 2
5.13-10 - GUIDE-INPUT 1
5.13-11 - CAP-LAMP_L 1
5.13-12 - FRAME-FUSER 1
5.13-13 - GUIDE-REAR 1
5.13-14 - LEVER-LINK JAM 2
5.13-15 - SPRING-ES 1
5.13-16 - HOLDER-JAM 2
5.13-17 - BRACKET-FUSER 1
5.13-18 - CAP-LAMP_R 1
5.13-19 - HOLDER-M_REAR_LEVER 1
5.13-20 - SPRING-CS 2
5.13-21 - SPRING-CS 2
5.13-22 - SPRING ETC-ACTUATOR 1
