Parts List
Phaser 3435 5/08 5-29
PL 14 Fuser Unit (2 of 2)
No. Part No. Description QT’y Remark
5.14-23 - GUIDE-CLAW 4
5.14-24 - SPRING ETC-CLAW 4
5.14-25 - PEX-ROLLER F/UP(2) 5
5.14-26 - IEX-SHAFT IDLE,F/UP 5
5.14-27 - SHAFT-EXIT_F/UP 1
5.14-28 - BUSH-TX 3
5.14-29 - RUBBER-EXIT_F/UP 2
5.14-30 - ACTUATOR-EXIT 1
5.14-31 - MEC-BRUSH ANTISTATIC 1
5.14-32 - ELECTRODE-EARTH 1
5.14-33 - GEAR-IDLE 23 FUSER 2
5.14-34 - BUSH-PR_1ST 2
5.14-35 - BUSH-PR_2ND 2
5.14-36 - SCREW-TAPTITE 4
5.14-37 - SCREW-TAPTITE 5
5.14-38 - SCREW-TAPTITE 3
5.14-39 130N01489 THERMISTOR-NTC ASSY 1
5.14-40 130N01490 THERMOSTAT 1
5.14-41 122N00260 LAMP-HALOGEN (110V) 1
5.14-41 122N00261 LAMP-HALOGEN (220V) 1
5.14-42 - CBF HARNESS-FUSER CON 1
5.14-43 - CBF HARNESS-FUSER (220V) 1
5.14-43 - CBF HARNESS-FUSER (110V) 1
5.14-44 - RING-E 2
5.14-45 - RING-E 4
