Parts List
Phaser 3435 5/08 5-31
PL 15 Cassette Unit
No. Part No. Description QT’y Remark
5.15-0 - MEA UNIT-CASSETTE 1
5.15-1 - ADJUST-M-CASSETTE_L 1
5.15-2 - ADJUST-M-CASSETTE_R 1
5.15-3 - GEAR-PINION 1
5.15-4 - MEA UNIT-HOLDER PAD 1
5.15-4-1 - HOLDER-M-PAD 1
5.15-4-2 - SHEET-HOLDER PAD R2 1
5.15-4-3 - IPR-PLATE PAD 1
5.15-4-4 - RPR-FRICTION PAD 1
5.15-5 - SPRING ETC-EXIT ROLL FD 1
5.15-6 - PLATE-P-KNOCK_UP 1
5.15-7 - SPRING-CS 2
5.15-7 - RPR-PAD CASSETTE 1
5.15-8 - CAM-M-KNOCK UP 1
5.15-9 - FRAME-M_CASSETTE 1
5.15-10 - GUIDE-M-EXTENSION L2 1
5.15-11 - PMO-EXTENSION SMALL 1
5.15-12 - PMO-PLATE_LOCKER 1
5.15-13 - SPRING ETC-LOCKER,PLATE 1
5.15-14 - COVER-M_SUB CST 1
5.15-15 - INDICATOR-M_CASSETTE 1
