Xerox PHASER 3435 Service Manual

General Procedures and Information
6-6 5/08 Phaser 3435
Consumables
Reliability & Service
Environment
Memory
The Phaser 3435 has 64MB of memory which can be expanded to 320MB.
Item Condition Description
Toner Black 4,000 pages @ ISO 19752 Coverage (Standard 4,000 pages,
High Yield10,000 pages)
Key Electronic key (CRUM) Only
Life detect Toner gauge sensor by dot count
Drum Yield 12,000 Images
Item Condition Description
Printing Volume (SET
AMPV)
- 9,200 sheets-per year / 767 sheets-per month / 38 sheets-per
day
5.2 Max. Monthly
Duty
- 35,000 sheets
5.3 MPBF - 100,000 sheets
5.4 MTTR - 30 min.
5.5 SET Life Cycle - 250,000 sheets or 5 years (whichever comes first)
5.6 RDS Comm. Mode Yes
Operation Yes
Item Condition Description
Acoustic Noise Level
(Sound Power/Pres-
sure)
Printing Less than 52.0 dBA
Standby Less than 26.0 dBA
Sleep Back Ground Level
Power Consumption Ready Less than 130W
AVG. Less than 400W
Max/Peak Less than 700W
Sleep/Power Off Less than 11W / Less than 0.4W
Dimension (W x D x H) SET 400 x 433 x 285 mm (15.7 x 17 x 11.2 inches)
Weight SET 10.5 kg (23.15 Pounds)
Gross 14.5kg (31.9 Pounds)

Xerox PHASER 3435 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Sound power level (standby)	25 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	Yes
Authentication method	IP filtering, 802.1x
Power consumption (active)	526 W
Maximum operating temperature range (T-T)	10 - 32 °C
Maximum duty cycle	80000 pages per month
Power consumption (standby)	36 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Certification	CB Report (IEC 60950-1/EN 60950-1), Certified to UL 60950-1/CSA 60950-1-03, 1st Edition, CE Marked, EMC Directive 2004/108/EC, FCC Part 15, Class B, Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC, RoHS Directive 2002/95/EC
