Xerox PHASER 3435 Service Manual

General Procedures and Information
6-12 5/08 Phaser 3435
Figure 7
LSU
• LSU is consist of LD (Laser Diode) and polygon motor control. When the controller generate
the printing signal LD will turn on and Polygon motor starts. If the receiving part in LSU detect
the beam and then Hsync is generated. When the rotation of polygon motor is steady, it is
time of LSU ready status for printing. If either of two condition is not satisfied, LSU error is
expected.
Print Cartridge
• OPC Cleaning: Mechanical Cleaning by the cleaning blade.
• The recycled toner: Trash room for the recycled toner
• No shutter for protecting the OPC Drum
Trouble Temperature Control Concept
Open Heat Error 50 degrees C for 20 sec at warm up
Over Heat Error 240 degrees C over for 2 sec or 220 degrees C over
for 20 sec at ready or printing.
200 degrees C over for 10 sec at standby.
Low Heat Error Standby: 130 degrees C below for 10 sec.
Printing: It 30 degrees C lower than target tempera-
ture for 20 sec.
Trouble Failure Analysis
Polygon Motor Error No steady rotation of Polygon Motor
Hsync Error In spite of steady rotation of Polygon Motor, There is
no generation of the Hsync signal

Xerox PHASER 3435 Specifications

General

Color	No
Maximum resolution	600 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	33 ppm
Internal memory	64 MB
Sound power level (standby)	25 dB
Total input capacity	300 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Media weight (tray 1)	60 - 163 gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Network ready	Yes
Authentication method	IP filtering, 802.1x
Power consumption (active)	526 W
Maximum operating temperature range (T-T)	10 - 32 °C
Maximum duty cycle	80000 pages per month
Power consumption (standby)	36 W
Power consumption (PowerSave)	11 W
Operating temperature (T-T)	50 - 90 °F
Operating relative humidity (H-H)	20 - 80 %
Certification	CB Report (IEC 60950-1/EN 60950-1), Certified to UL 60950-1/CSA 60950-1-03, 1st Edition, CE Marked, EMC Directive 2004/108/EC, FCC Part 15, Class B, Low Voltage Directive 2006/95/EC, R&TTE Directive 1999/5/EC, RoHS Directive 2002/95/EC
