General Procedures and Information
Phaser 3435 5/08 6-35
SCREW-TAPTITE;PWH,+,B,M3,L10,NI
PLT,SWRCH18A
3
Frame Dup+Bracket Align
Dup
SCREW-TAPTITE;PWH,+,B,M3,L10,NI
PLT,SWRCH18A
2
Frame Dup+Guide Upper
Dup
SCREW-TAPTITE;PWH,+,B,M3,L10,NI
PLT,SWRCH18A
4
COVER FRONT+HOLDER
LOCKER
SCREW-TAPTITE;PWH,+,B,M3,L10,NI
PLT,SWRCH18A
2
COVER MIDDLE+CAP SUB
ACTUATOR
SCREW-TAPTITE;PWH,+,B,M3,L10,NI
PLT,SWRCH18A
1
PBA+COVER KEY
MENU_LCD
SCREW-TAPTITE;PWH,+,B,M3,L10,NI
PLT,SWRCH18A
4
COVER CAS-
SETTE+FRAME CASSETTE
SCREW-TAPTITE;PWH,+,B,M3,L10,NI
PLT,SWRCH18A
2
S5(WH
Long)
BLDC MOTOR+BRKT
MOTOR
SCREW-TAPTITE;PWH,+,-
,S,M4,L8,ZPC(WHT),SWRCH18A,
4
S6(BH
Short)
PLATE KNOCKUP+CAM
KNOCKUP
SCREW-TAPTITE;BH,+,-
,B,M3,L6,ZPC(WHT),SWRCH18A,
1
S7(WH
Short)
TRAY ASF INPUT
UPPER+GEAR PINION
SCREW-TAPTITE;PWH,+,-
,B,M3,L6,ZPC(WHT),SWRCH18A,
1
SCREW-TAPTITE;PWH,+,-
,B,M3,L6,ZPC(WHT),SWRCH18A,
2
LCD+COVER KEY
MENU_LCD
SCREW-TAPTITE;PWH,+,-
,B,M3,L6,ZPC(WHT),SWRCH18A,
2
GEAR PINION+FRAME
CASSETTE
SCREW-TAPTITE;PWH,+,-
,B,M3,L6,ZPC(WHT),SWRCH18A,
1
S8(BH
Short)
BRKT MOTOR+BRKT GEAR SCREW-TAPTITE;BH,+,-
,S,M3,L6,ZPC(WHT),SWRCH18A,
4
SHIELD CONTROL-
LER+PBA
SCREW-TAPTITE;BH,+,-
,S,M3,L6,ZPC(WHT),SWRCH18A,
3
SHIELD SMPS+SMPS SCREW-TAPTITE;BH,+,-
,S,M3,L6,ZPC(WHT),SWRCH18A,
4
HVPS+SHIELD HVPS SCREW-TAPTITE;BH,+,-
,S,M3,L6,ZPC(WHT),SWRCH18A,
3
SCREW-TAPTITE;BH,+,-
,S,M3,L6,ZPC(WHT),SWRCH18A,
2
SCREW-TAPTITE;BH,+,-
,S,M3,L6,ZPC(WHT),SWRCH18A,
4
S9(BH
Short)
SCREW-TAPTITE;BH,+,-
,B,M3,L8,ZPC(BLK),SWRCH18A,
8
SCREW-TAPTITE;BH,+,-
,B,M3,L8,ZPC(BLK),SWRCH18A,
5
SCREW-TAPTITE;BH,+,-
,B,M3,L8,ZPC(BLK),SWRCH18A,
10
S10(BH
Long)
SHIELD SMPS+EARTH
HARNESS
SCREW-TAPTITE;BH,+,-
,S,M4,L6,ZPC(WHT),SWRCH18A,
1
To Next Page
