6-34
Phaser 3635MFP
dC131
Draft 4
General Procedures and Information
NOTE: If the NVM default characters exceed 10 characters only the first eight characters are
displayed in the list. The full string is displayed in the Read/Write window.
NOTE: Selecting Reset will cause the selected NVM location to be reset to its default value.
Selecting Cancel closes the window and cancels any changes made in the now closed win-
dow.
NOTE: The CSE cannot read or modify any NVM that contains customer administrative or
accounting data.
NOTE: The Read Only (protected) NVM can only be changed using a password obtained from
Xerox.
Table 1 NVM chain 6
Location NVM Name NVM Description Value Default
06-100 Vertical Magni-
tude
The changed dimension of the
vertical direction magnitude.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
06-110 Horizontal Magni-
tude
The changed dimension of the
horizontal direction magnitude.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
Table 2 NVM chain 7
Location NVM Name NVM Description Value Default
07-100 Top Registration
Tray 1 Simplex
The changed dimension of tray
1 top registration in simplex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-110 Side Registration
Tray 1 Simplex
The changed dimension of tray
1 side registration in simplex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-120 Top Registration
Tray 1 Dup_long
(2nd side)
The changed dimension of tray
1 top registration of 2nd side in
duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-130 Side Registration
Tray 1 Dup_long
(2nd side)
The changed dimension of tray
1 side registration of 2nd side
in duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-140 Top Registration
Tray 1 Duplex
(1st side)
The changed dimension of tray
1 top registration of 1st side in
duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-150 Side Registration
Tray 1 Duplex
(1st side)
The changed dimension of tray
1 side registration of 1st side in
duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-200 Top Registration
Tray 2 Simplex
The changed dimension of tray
2 top registration in simplex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-210 Side Registration
Tray 2 Simplex
The changed dimension of tray
2 side registration in simplex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-220 Top Registration
Tray 2 Dup_long
(2nd side)
The changed dimension of tray
2 top registration of 2nd side in
duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-230 Side Registration
Tray 2 Dup_long
(2nd side)
The changed dimension of tray
2 side registration of 2nd side
in duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-240 Top Registration
Tray 2 Duplex
(1st side)
The changed dimension of tray
2 top registration of 1st side in
duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-250 Side Registration
Tray 2 Duplex
(1st side)
The changed dimension of tray
2 side registration of 1st side in
duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-500 Top Registration
Bypass Simplex
The changed dimension of
bypass top registration in sim-
plex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-510 Side Registration
Bypass Simplex
The changed dimension of
bypass side registration in sim-
plex.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-520 Top Registration
Bypass Dup_long
(2nd side)
The changed dimension of
bypass top registration of 2nd
side in duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-530 Side Registration
Bypass Dup_long
(2nd side)
The changed dimension of
bypass side registration of 2nd
side in duplex long.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-540 Top Registration
Bypass Duplex
(1st side)
The changed dimension of
bypass top registration of 1st
side in duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
07-550 Side Registration
Bypass Duplex
(1st side)
The changed dimension of
bypass side registration of 1st
side in duplex long and short.
0mm to 6mm
(12 steps /
0.5mm seg.)
3
Table 3 NVM chain 9
Location NVM Name NVM Description Value Default
09-100 LD Light Level 600dpi laser light level. Value
in PWM.
200 to 600 350
09-110 MHV Control Bias
Control
Main charge bias control.
Basic of value (HVPS setting is
value). Value in PWM.
108 to 145 126
09-120 THV Bias Control
Control
Transfer bias control. Basic of
value (HVPS setting is value).
Value in PWM.
41 to 220 76
09-130 Deve Bias Control DEVE bias control. Basic of
value (HVPS setting is value).
Value in PWM standard volt-
age: --500V (PWM 522).
408 to 607 522
