6-35
Phaser 3635MFP
dC131
General Procedures and Information
Draft 4
09-140 Detack Bias Con-
trol
Detack bias control. Basic of
value (HVPS setting is value).
Value in PWM standard volt-
age: -1800V.
80 to 160 123
09-205 Print Cartridge
Life Page Counter
Display of print cartridge pages
count.
(Read only)
09-230 Transfer Roller
Life Page Counter
Display value of pages count. (Read only)
Table 4 NVM chain 10
Location NVM Name NVM Description Value Default
10-200 Fuser Life Page
Counter
(Read only) Total fuser page
count
10-210 Heat Roll Life
Page Counter
(Read only) Heat roll page
count
10-220 Pressure Roll Life
Page Counter
(Read only) Pressure roll page
count
10-300 Pick-up Interval
Delay
Change the time interval for
paper pick-up.
0 to 100 msec. 0
10-310 Pick-up Interval
Delay (Special
Paper)
Change the time interval for
paper pick-up.
0 to 100 msec. 0
Table 5 NVM chain 20
Location NVM Name NVM Description Value Default
20-100 Redial Attempts Number of times to
redial.
1 to 13 7
20-110 Redial Interval Time between each
redial.
1 to 15 3
20-200 Pause Dial Time Time of each pause. 0 to 200 (1000 msec.) 4
20-210 Dial Pulse M/B
Ratio
Dial pulse make/break
ratio.
33/66 (0)
40/60 (1)
1
20-220 Auto Dial Start
Pause Time
Pause time before auto-
dialing (second)
0 to 10 seconds 1
20-300 Ring On Time Ring on time. 90 to 800msec. 90
20-310 Ring Off Time Ring off time. 90 to 800msec. 90
20-320 Ring Detection
Freq
Call indication fre-
quency range.
12 to 80Hz (1)
16 to 55Hz (2)
20 to 55hz (3)
22 to 55hz (4)
1
20-400 DTMF High-Freq
Level
DTMF high frequency
level.
0 to 15dBm 8
20-410 DTMF Low-Freq
Level
DTMF low frequency
level.
0 to 15dBm 11
Table 3 NVM chain 9
Location NVM Name NVM Description Value Default
20-420 DTMF Timing DTMF duration of on/off
output.
80/80 (1)
70/70 (2)
70/150 (3)
60/60 (4)
80/100 (5)
150/50 (6)
150/240 (7)
1
20-500 Dial Mode Dial mode selection. Tone (0) / Pulse (1) 0
20-510 ECM Mode ECM mode on or off. Off (0)
On (1)
0
20-520 Error Rate Adjusts the error rate. Off (0) / 5% (1) / 10% (2) /
20% (3)
0
20-530 Dial Tone Detect Detects dial tone prior to
sending.
Off (0)
On (1)
0
20-540 Loop Current
Detect
Detects if loop current is
present prior to sending.
Off (0)
On (1)
0
20-550 Busy Signal
Detect
Detects a busy signal to
allow redials.
Off (0)
On (1)
0
20-700 Line Monitor
Setting
Audio line monitor. Off (0)
On (1)
Comm (2)
0
20-800 Modem Speed Select modem start
speed.
Modem_V21_300bps (0)
Modem_V27_2400bps (1)
Modem_V27_4800bps (2)
Modem_V29_7200bps (3)
Modem_V29_9600bps (4)
Modem_V33_12000bps (5)
Modem_V33_14400bps (6)
Modem_V17_7200bps (7)
Modem_V17_9600bps (8)
Modem_V17_12000bps (9)
Modem_V17_14400bps (10)
Modem_V34_2400bps (11)
Modem_V34_4800bps (12)
Modem_V34_7200bps (13)
Modem_V34_9600bps (14)
Modem_V34_12000bps (15)
Modem_V34_14400bps (16)
Modem_V34_16800bps (17)
Modem_V34_19200bps (18)
Modem_V34_21600bps (19)
Modem_V34_24000bps (20)
Modem_V34_26400bps (21)
Modem_V34_28800bps (22)
Modem_V34_31200bps (23)
Modem_V34_33600bps (24)
0
Table 5 NVM chain 20
Location NVM Name NVM Description Value Default
