Xerox WorkCentre 3119 Service Manual

Spare Parts List
WorkCentre 3119 06/06 5-15
PL 7 Scan Assembly
Item Part Number Description Remark
0 062N00275 SCAN ASSEMBLY REP 6
1 002N02615 PLATEN COVER
1-1 002N02616 COVER-M-PLATEN
1-2 SHEET-WHITE SPONGE
1-3 HINGE-M_PIVOT
2 ELA UNIT- SCAN UPPER ASSEMBLY
2-1 002N02617 ELA-UNIT-SCAN UPPER
2-2 LABEL(P)-SHADING
2-3 GLASS-PLATEN
2-4 TAPE
2-5 GLASS-PLATEN TAPE
3 007N01552 SCAN MOTOR ASSEMBLY
3-1 MOTOR STEP-SCAN UPPER
3-2 BRACKET MOTOR-P-SCAN
3-3 007N01549 BELT-TIMING GEAR
3-4 GEAR-M_PULLEY
4 CBF SIGNAL-CIS HARNESS
5 130N01484 CIS (CONTACT IMAGE SENSOR)
6BELT
7 002N02618 COVER SCAN LOWER
8 SHEET-SCAN LOWER
9 BRACKET-P-PULLEY
10 PULLEY-M_IDLE
11 SPRING-CS
12 SLIDER-M_CIS R
13 SLIDER-M_CIS L
14 ELA UNIT-OPE
15 BELT CLIP
16 CIS SUPPORT BAR
17 CIS BRACKET
18 SPRING

Xerox WorkCentre 3119 Specifications

General

Print Technology	Laser
Print Speed	19 ppm
Print Resolution	600 x 600 dpi
Copy Speed	19 cpm
Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Scanner Type	Flatbed
Memory (Standard)	32 MB
Operating System Compatibility	Windows, Mac
