Xerox WorkCentre 3119 Service Manual

Status Indicator RAPs
WorkCentre 3119 07/06 2-19
15 Abnormal Noise RAP
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
There is an abnormal noise from the printer during operation.
Check and Cause Solution
1. If the abnormal noise is only heard during
scanning, check the Scan Motor Assembly
and gears, PL 7. Ensure no parts are dam-
aged and there are no foreign objects in the
mechanism or scan path.
1. Install new parts as necessary:
• Belt timing gear, PL 7
• Scan motor assembly, PL 7
• CIS, PL 7
2. Check the LSU motor, step motor (drive)
and toner fan using Engine Test Mode, GP 4.
Check the Step Motor (Drive) connector on
the Main PBA, PL 1.
2. Install new parts as necessary:
• Toner Fan, PL 1
•LSU, PL 1
• Motor Assembly, PL 6
• Main PBA, PL 1

Xerox WorkCentre 3119 Specifications

General

Print Technology	Laser
Print Speed	19 ppm
Print Resolution	600 x 600 dpi
Copy Speed	19 cpm
Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Scanner Type	Flatbed
Memory (Standard)	32 MB
Operating System Compatibility	Windows, Mac
