Xerox WorkCentre 3119 Service Manual

Status Indicator RAPs
2-12 07/06 WorkCentre 3119
8 Fuser Error RAP
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
A message “Open Heat Error/Over heat/Heating Error” is displayed.
Check and Cause Solution
1. Drive gear, PL 6 has melted. 1. Check the drive assembly, PL 6. Install a
new drive assembly if necessary.
2. Check the halogen lamp operation using
Engine Test Mode, GP 4.
2. Install new parts as necessary:
• Halogen lamp, PL 5
•Fuser, PL 5
3.Check the thermistor, PL 5 for damage. 3. Install new parts as necessary:
• Thermistor, PL 5
• Fuser, PL 5
4. Check the following parts:
• Thermostat, PL 5
• Fuser harness, PL 5
• Halogen lamp, PL 5
4. Install new parts as necessary:
• Fuser harness, PL 5
• Thermostat, PL 5
• Halogen lamp, PL 5
•Fuser, PL 5

Xerox WorkCentre 3119 Specifications

General

Print Technology	Laser
Print Speed	19 ppm
Print Resolution	600 x 600 dpi
Copy Speed	19 cpm
Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Scanner Type	Flatbed
Memory (Standard)	32 MB
Operating System Compatibility	Windows, Mac
