Xerox WorkCentre 3119 Service Manual

Status Indicator RAPs
WorkCentre 3119 07/06 2-15
11 Paper Empty RAP
WARNING
Switch off the electricity to the machine. Disconnect the power cord from the customer supply
while performing tasks that do not need electricity. Electricity can cause death or injury. Moving
parts can cause injury.
Description
Paper Empty is displayed when paper is loaded in the cassette.
The paper empty message is not displayed when the paper cassette is empty.
Check and Cause Solution
1. Faulty cables or connectors. 1. Check the cables and connectors.
2. Check the paper empty sensor operation
using Engine Test Mode, GP 4.
The paper sensor actuator (cassette), PL 4
may be deformed.
Note: The Paper Empty Sensor is mounted
onto the SMPS/HVPS, PL 1.
2. Install new parts as necessary:
• Paper sensor actuator (cassette), PL 4
• Main PBA, PL 1
3. The SMPS/HVPS or Main PBA, PL 1 is
faulty.
3. Install new parts as necessary:
• SMPS/HVPS, PL 1
• Main PBA, PL 1

Xerox WorkCentre 3119 Specifications

General

Print Technology	Laser
Print Speed	19 ppm
Print Resolution	600 x 600 dpi
Copy Speed	19 cpm
Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Scanner Type	Flatbed
Memory (Standard)	32 MB
Operating System Compatibility	Windows, Mac
