Xerox WorkCentre 3119 Service Manual

General Procedures and Information
WorkCentre 3119 06/06 6-37
4. Pull the paper out gently.
Figure 5
5. Close the jam cover by pushing the support tab to the left and hold it down whilst lowering the
cover carefully until the cover fully down, this will hold down the tab. If there is any resistance
and the paper does not move when you pull or if you cannot see the paper in the jam cover,
continue to step 6.
6. Open the rear cover.
7. Remove the jammed paper by gently pulling it straight out.
Figure 6
8. Close the rear cover.
9. Open and close the front cover to resume printing.
In the Fuser Area or Around the Toner Cartridge
Note: The fuser area is hot. Take care when removing paper from the machine.

Xerox WorkCentre 3119 Specifications

General

Print Technology	Laser
Print Speed	19 ppm
Print Resolution	600 x 600 dpi
Copy Speed	19 cpm
Copy Resolution	600 x 600 dpi
Paper Capacity	250 sheets
Connectivity	USB 2.0
Functions	Print, Copy, Scan
Scanner Type	Flatbed
Memory (Standard)	32 MB
Operating System Compatibility	Windows, Mac
