Xerox WorkCentre 3119

Repairs/Adjustments
WorkCentre 3119 06/06 4-3
REP 1 Front Cover
Parts list on PL 2
Switch off the electricity to the machine. Dis-
connect the power cord from the customer
supply while performing tasks that do not
need electricity. Electricity can cause death or
injury. Moving parts can cause injury.
1. Remove the cassette assembly, Figure 1.
Figure 1
2. Open the front cover, Figure 2.
Figure 2
3. Gently flex the front cover in the direction
of the arrows and remove the front cover,
Figure 3.
Figure 3
